Item Main Technical Parameters |
|||
|
Model |
WC19RJ(A) |
||
|
Curb weight |
5270 |
||
|
Rated passenger capacity (person) |
19 |
||
|
Overall Dimensions L×W×H (mm) |
6150 x2000 x 2320 |
||
|
Wheelbase (mm) |
3330 |
||
|
Front Track (mm) |
1620 |
||
|
Rear Track (mm) |
1560 |
||
|
Minimum Ground Clearance (Loaded, mm) |
165 |
||
|
Gradeability (°) |
14 |
||
|
Rear Overhang (mm) |
1750 |
||
|
Travel Speed per Gear (km/h) |
1st Gear |
3 |
|
|
2nd Gear |
5 |
||
|
3rd Gear |
12 |
||
|
4th Gear |
18 |
||
|
5th Gear |
25 |
||
|
Reverse Gear |
10 |
||
|
Minimum Turning Radius (mm) |
Inside (mm) |
5650 |
|
|
Outside(mm) |
8750 |
||
|
Maximum Traction Force (kN) |
≥30 |
||
|
Transmission Type |
Mechanical Transmission |
||
|
Braking Type |
Service Brake |
Four-wheel braking, hydraulic release, wet disc brakes |
|
|
Emergency Brake |
Rear-wheel braking, spring-applied brake, hydraulic release, wet disc brakes |
||
|
Parking Brake |
Central braking, spring-applied brake, hydraulic release, wet disc brakes |
||
|
Drive Type |
4-wheel drive |
||
|
Flameproof Diesel Engine Model |
ZL4105DZLDFB |
||
|
Flameproof Diesel Engine Power (kW) |
62 |
||
|
Flameproof Diesel Engine Rated Speed (r/min) |
2200 |
||
|
Protection Type |
Flameproof electric protection |
||
